- Ultra-quiet drive design, precision control, little vibration and noise.
- Plastic-coated metal housing, compact structure.
- Timing function, time range 0.5s-999s, can be used for simple dispensing.
- RS232, RS485 communication interface. Supports Shenchen communication protocol or standard Modbus communication protocol (RTU mode).
| Drive | Pump Head | Tubing Size | Speed | Flow Rate(mL/min) |
| BT300M | YZ1515x | 13#，14#，19#，16#，25#，17#，18# | 1-350rpm | 0.07-1330 |
| YZ2515x | 15#，24# | 1.7-1015 | ||
| MC1-MC12(10) | Diameter：0.13-3.17mm Wall thickness：0.86-1mm |
0.00166-49(suggestionworking speed≤150rpm) | ||
| MC1-MC12(6) | 0.00185-65(suggestionworking speed≤150rpm) |
- Change the tubing easily and rapidly; automatic tubing retention; accept 9 sizes tubing to meet different flow-rate requests.
- Two kinds of material housing for customers' selection. PSF (polysulphone material): white, exquisite appearance, good rigidity, high precision, usually used in research laboratory and supporting analytical device. PPS (polyphenylene sulfide material): black, resistant to organic solvent corrosion, high precision and rigidity, suitable for industry or other harsh working conditions.
- Roller assembly with 304 stainless steel material, corrosion-resistant with long lifetime.
| Tubing | 13#(Thickness0.8mm) | 14#(Thickness1.6mm) | 19#(Thickness2.4mm) | 16#(Thickness3.1mm) |
| 1-350rpm/min | 0.07-24.5 | 0.27-94.5 | 0.55-192.5 | 0.82-287 |
| Tubing | 25#(Thickness4.8mm) | 17#(Thickness6.4mm) | 18#(Thickness7.9mm) | |
| 1-350rpm/min | 1.7-595 | 2.8-980 | 3.8-1330 |
Operation Demonstration
