V1
    Speed range：0.1-150 rpm
    Flow range：0.0053-295 mL/min
Optional pump head：
EasyPump
AMC
YZ1515x
YZ2515x
Online consultation
Download

Product Introduction

  • Dynamic display transferring status. Flow rate data, setting parameters and system configuration display in the same screen.
  • Four-working modes: Fixed volume, volume dispensing, speed dispensing, and timing start/stop functions meet complex transmission and dispensing requirements.
  • Intelligent calibration function and online micro adiusting function, can be in the case of not stop, adiust the flow, eliminate the error.
  • Streamlined body design, with ABS Engineering Plastic Shell and add UV Spray Coating.
  • Circuit board three layers of paint spraying process, dust proof, moisture proof, anti-static, corrosion resistance.

Technical Parameter

Flow rate range 0.0002-645 mL/min
Speed range 0.1-150 rpm
Speed resolution 0.01 rpm
Flow rate resolution 0.01 mL
Dispensing volume 0.01-9999mL
Volume resolution 0.01mL
Dispensing time 0.1-9999s
Pause time 0.1-9999s
Time resolution 0.01s
Repeat number 1-9999 times, setting"0" as infinite/continuous dispensing
Flow rate accuracy < ±0.5%
Back suction angle 0-360°
Motor type Stepper motor
Display Industrial grade 4.3" LCD color display
Control method Touch screen and mechanical keypad
Keypad lifetime 300,000 times
External control signal 0-5V, 0-10V, 4-20mA (for option)
Start/stop, direction signal Passive switch signal, such as foot pedal switch; Active switch signal: 5V-24V
Communication interface RS232, RS485 support MODBUS protocol (RTU mode)
Output interface Output motor working status (Open-Collector output)
Power supply AC 220V±10% 50Hz/60Hz (standard), AC 110V±10% 50Hz/60Hz (optional)
Drive dimension (L×W×H) 219.6×152×211.6 mm
Drive weight 4.20 kg
Power consumption < 50W
Condition temperature 0-40℃
Relative humidity < 80%

Pump Head Parameter

Drive Pump Head Tubing Size Speed Flow rate(mL/min)
V1 EasyPump I/III 13#, 14#, 19#, 16#, 25#, 17#, 18# 0.1-150rpm 0.0053-645
EasyPump II/IV 15#, 24# 0.18-410
EasyPump V/VI 13#, 14#, 19#, 16#, 25# 0.0053-295
2*EasyPump I/III 13#, 14#, 19#, 16#, 25# 0.0053-295
2*EasyPump II/IV 15# 0.18-270
2*EasyPump V/VI 13#, 14#, 19#, 16# 0.0053-140
AMC1-AMC12(10) Inner diameter:0.13-3mm
Wall thickness:0.8-1mm		 0.0002-48(suggestion working speeds ≤150rpm)
AMC1-AMC12(6) 0.0002-65(suggestion working speeds ≤150rpm)
YZ1515x 13#, 14#, 19#, 16#, 25#, 17#, 18# 0.007-570
YZ2515x 15#, 24# 0.17-435

OSD

Dimension（Unit：mm）
