CF600 PlusIV is integrated type filling system with low driven by servo motor. One controller control 8 groups, each groups with 8 filling units, total 32 filling units. 4.3" true color display with touch screen control. Using YZ35 high flow rate pump head. Filling accuracy up to 0.5%-1%. Touch screen control, can preset filling volume, filling time, pause time, copy numbers and back suction angle. Dynamic display the working status, filling data, setting parameters and system configuration. Intelligent calibration and micro adjusting function. Industry application: Support Pharmaceutical machine, filling machine, Pharmaceutical, cosmetic, food, beverage dispensing.
| Product Composition and Flow Rate Range |
| Drive | Pump Head | Housing material | Tube clamp/connector material | Tubing | （Motor speed 0.1-600rpm） Flow rate range mL/min |
|
| Tubing size | ID×Wall thickness(mm) | |||||
| CF600 Plus IV | YZ35-PPS | PPS | PP | 26# | 6.4×3.3 | 0.69-4200 |
| 73# | 9.6×3.3 | 1.23-7400 | ||||
| 82# | 12.7×3.3 | 2-12000 | ||||
| Filling Volume Reference (Media is water) |
| Drive | Pump Head | Tubing | Filling Volume（mL） | Filling Time（s） | Accuracy（±%） | Output（pcs/min） | Motor Speed（rpm） |
| CF600 Plus IV | YZ35-PPS | 26# | 50 | 1 | 0.5 | 30 | 434.78 |
| 26# | 100 | 2 | 20 | 434.78 | |||
| 73# | 100 | 1.2 | 27 | 406.50 | |||
| 73# | 150 | 2 | 20 | 365.85 | |||
| 82# | 200 | 1.5 | 24 | 400.00 | |||
| 2*YZ35 | 26# | 100 | 1.2 | 27 | 203.25 | ||
| 73# | 200 | 1.5 | 24 | 325.20 | |||
| 82# | 500 | 2 | 20 | 375.00 |
