CF series split-type intelligent filling system consisting of one controller and several (total 16) filling units. Units can be added or deleted according to requirements. Features a 4.3" true color touch screen display with an accuracy range of ±0.5%-1%.

The system offers intelligent calibration and online micro-adjustment functions. Supports connectivity to foot pedal switches or external signal reception for remote control. Provides a unique motor status output signal for real-time monitoring.

Industry applications: Pharmaceutical machines, filling equipment, pharmaceuticals, cosmetics, food, beverage dispensing, and oral liquid filling.

Product Composition and Flow Range

Drive	Drive	Tubing size	ID×Wall Thickness(mm)	(Motor Speed 0.1-600rpm) Flow Rate mL/min
CF600 Plus II	Single Channel EasyPump I/III	13#	0.8x1.6	0.0053-32
		14#	1.6x1.6	0.027-162
		19#	2.4x1.6	0.055-330
		16#	3.2x1.6	0.093-560
		25#	4.8x1.6	0.197-1180
		17#	6.4x1.6	0.333-2000
		18#	7.9x1.6	0.430-2580
	Single Channel EasyPump II/IV	15#	4.8x2.4	0.180-1080
		24#	6.4x2.4	0.273-1640
		35#	7.9x2.4	0.383-2300
		36#	9.6x2.4	0.517-3100
	Dual Channel EasyPump V/VI	13#	0.8x1.6	0.0053-32
		14#	1.6x1.6	0.027-162
		19#	2.4x1.6	0.055-330
		16#	3.2x1.6	0.093-560
		25#	4.8x1.6	0.197-1180

Drive	Pump Head	Pump Head Material	Tube Clamp Material	Tubing		（Motor Speed 0.1-600rpm） Flow Rate mL/min
				Tubing size	ID×Wall Thickness(mm)
CF600Plus II	DZ25-3L	PPS	PP	15#	4.8×2.4	0.211-1264
				24#	6.4×2.4	0.385-2310
				35#	7.9×2.4	0.508-3050
				36#	9.6×2.4	0.6-3600

Filling Volume Reference (Media is water)

Drive	Pump Head	Tubing	Filling Volume（mL）	Filling Time（s）	Accuracy（±%）	Output（pcs/min）	Moter Speed（rpm）
CF600Plus II	DZ25-3L	15#	16	1	0.5	30	454.976
		24#	30	1.2	0.5	27	389.610
		35#	150	4	0.5	12	442.913
		36#	200	4	0.5	12	500.000

Drive	Pump Head	Tubing	Filling Volume（mL）	Filling Time（s）	Accuracy（±%）	Output（pcs/min）	Motor Speed（rpm）
CF600Plus II	EasyPump	13#	0.4	1.2	0.8	27	377.36
		13#	1	2.5	0.5	17	452.83
		14#	2	1	0.5	30	444.44
		19#	5	1.2	0.5	27	454.55
		16#	7	1	0.5	30	450.16
		25#	10	0.8	0.8	33	381.29
		25#	15	1	0.5	30	457.55
		25#	20	1.5	0.5	24	406.71
		17#	30	1.2	0.5	27	450.05
		18#	50	1.5	0.5	24	465.12
		15#	15	1.2	0.5	27	416.67
		24#	20	1.2	0.5	27	365.90
		35#	30	1.2	0.5	27	391.34
		36#	50	1.5	0.5	24	387.07
	2*EasyPump	13#	0.5	0.8	0.8	33	353.77
		13#	1	1.2	0.5	27	471.70
		14#	2	0.6	1	38	370.37
		14#	5	1.5	0.5	24	370.37
		19#	10	1.2	0.5	27	454.55
		16#	15	1.2	0.5	27	410.93
		16#	20	1.5	0.5	24	428.72
		25#	30	1	0.5	30	457.55
		17#	50	1	0.5	30	450.05
		18#	70	1	0.5	30	488.37
		15#	30	1.2	0.5	27	416.67
		24#	50	1.2	0.5	27	457.37
		35#	70	1.2	0.5	27	456.56
		36#	100	1.5	0.5	24	387.07
