DF series integrated-type filling system with low pulsation driven by a servo motor. One controller controls 4 groups, each group with 4 filling units, totaling 16 filling units. Features a 4.3-inch true color touch-screen display. Uses DZ25-6L high-flow-rate pump head. Filling accuracy: ±0.5%-1%. Includes intelligent calibration and online micro-adjusting functions. Can be connected with a foot-pedal switch or receive switch signals to achieve external control. The unique motor working status output signal is for monitoring the filling status.
Industry applications: Supports pharmaceutical machines, filling equipment, and is used in pharmaceuticals, cosmetics, food, beverage dispensing, and oral liquid filling.
| Product Composition and Flow Rate Range |
| Drive | Pump Head | Housing Material | Tube clamp/ connector material |
Tubing | （Motor speed 0.1-600rpm） Flow rate range mL/min |
|
| Tubing size | ID×Wall thickness(mm) | |||||
| DF600 Plus III | DZ25-6L | Aluminum alloy | PP | 15# | 4.8×2.4 | 0.3-1800 |
| 24# | 6.4×2.4 | 0.55-3300 | ||||
| 35# | 7.9×2.4 | 0.8-4800 | ||||
| 36# | 9.6×2.4 | 1-6000 | ||||
| Filling Volume Reference Parameter(Media is water) |
| Drive | Pump Head | Tubing | Filling Volume （mL） |
Filling Time（s） | Accuracy（±%） | Output （pcs/min） |
Motor Speed （rpm） |
| DF600 Plus III | DZ25-6L | 15# | 30 | 1.2 | 0.5 | 27 | 500.00 |
| 24# | 50 | 1.2 | 0.5 | 27 | 454.55 | ||
| 35# | 70 | 1.2 | 0.5 | 27 | 437.50 | ||
| 36# | 100 | 1.5 | 0.5 | 24 | 400.00 |
Back-suction angle
Calibration
Effective unit
Pump head and tubing setting and 3times filling demonstration
Speed knob demonstration
