DF series intelligent-type integrated filling system consists of a control unit and integrated filling units. Each group has 4 filling units. One controller controls 4 groups, totaling 16 filling units. Features a 4.3-inch color touch screen display that dynamically shows the working status, filling data, setting parameters, and system configuration. Filling precision: ±0.5%-1%. Includes intelligent calibration and online micro-adjusting functions. Can be connected with a foot-pedal switch or receive a switch signal to achieve external control. The unique motor working status output signal is used for monitoring the filling status.

Industry applications: Supports pharmaceutical machinery, filling equipment, pharmaceutical, cosmetic, food, beverage dispensing, and oral liquid filling.

Product Composition and Flow Rate Range

Pump Head	Single/Dual Channel	Tubing Wall Thickness(mm)	Pressure Adjustable
EasyPump l	Single Channel	1.6	No
EasyPump II	Single Channel	2.4	No
EasyPump V	Dual Channel	1.6	No

Pump Head	Single/Dual Channel	Tubing Wall Thickness(mm)	Pressure Adjustable
EasyPump III	Single Channel	1.6	Adjustable
EasyPump IV	Single Channel	2.4	Adjustable
EasyPump Vl	Dual Channel	1.6	Adjustable

Pump Head	Tubing	ID×Wall thickness(mm)	mL/r	Flow Rate(mL/min) (0.1-150rpm)	Tubing Max.Pressure(Mpa)		Weight(kg)
					Intermittent	Continuous
Single Channel EasyPump I/III	13#	0.8x1.6	0.053	0.0053-32	0.27	0.17	0.6
	14#	1.6x1.6	0.27	0.027-162
	19#	2.4x1.6	0.55	0.055-330
	16#	3.2x1.6	0.933	0.0933-560
	25#	4.8x1.6	1.967	0.1967-1180	0.24	0.14
	17#	6.4x1.6	3.333	0.3333-2000	0.14	0.10
	18#	7.9x1.6	4.3	0.431-2580	0.10	0.07
Single Channel EasyPump II/IV	15#	4.8x2.4	1.8	0.18-1080	0.27	0.17
	24#	6.4x2.4	2.733	0.2733-1640
	35#	7.9x2.4	3.833	0.3833-2300	0.24	0.14
	36#	9.6x2.4	5.167	0.5167-3100
Dual Channel EasyPump V/VI	13#	0.8x1.6	0.053	0.0053-32	0.27	0.17
	14#	1.6x1.6	0.27	0.027-162
	19#	2.4x1.6	0.55	0.055-330
	16#	3.2x1.6	0.933	0.0933-560
	25#	4.8x1.6	1.967	0.1967-1180	0.24	0.14

Drive	Pump Head	Pump Head Material	Tube Clamp Material	Tubing		（Motor Speed 0.1-600rpm） Flow Rate mL/min
				Tubing size	ID×Wall Thickness(mm)
DF600 Plus II	DZ25-3L	Aluminum alloy/PPS	PP	15#	4.8×2.4	0.211-1264
				24#	6.4×2.4	0.385-2310
				35#	7.9×2.4	0.508-3050
				36#	9.6×2.4	0.6-3600

Filling Volume Reference Parameter(Media is water)

Drive	Pump Head	Tubing	Filling Volume（mL）	Filling Time（s）	Accuracy（±%）	Output（pcs/min）	Motor Speed（rpm）
DF600Plus	DZ25-3L	15#	16	1	0.5	30	454.976
		24#	30	1.2	0.5	27	389.610
		35#	150	4	0.5	12	442.913
		36#	200	4	0.5	12	500.000

Drive	Pump Head	Tubing	Filling Volume（mL）	Filling Time（s）	Accuracy（±%）	Output（pcs/min）	Motor Speed（rpm）
DF600Plus II	EasyPump	13#	0.4	1.2	0.8	27	377.36
		13#	1	2.5	0.5	17	452.83
		14#	2	1	0.5	30	444.44
		19#	5	1.2	0.5	27	454.55
		16#	7	1	0.5	30	450.16
		25#	10	0.8	0.8	33	381.29
		25#	15	1	0.5	30	457.55
		25#	20	1.5	0.5	24	406.71
		17#	30	1.2	0.5	27	450.05
		18#	50	1.5	0.5	24	465.12
		15#	15	1.2	0.5	27	416.67
		24#	20	1.2	0.5	27	365.90
		35#	30	1.2	0.5	27	391.34
		36#	50	1.5	0.5	24	387.07
	2*EasyPump	13#	0.5	0.8	0.8	33	353.77
		13#	1	1.2	0.5	27	471.70
		14#	2	0.6	1	38	370.37
		14#	5	1.5	0.5	24	370.37
		19#	10	1.2	0.5	27	454.55
		16#	15	1.2	0.5	27	401.93
		16#	20	1.5	0.5	24	428.72
		25#	30	1	0.5	30	457.55
		17#	50	1	0.5	30	450.05
		18#	70	1	0.5	30	488.37
		15#	30	1.2	0.5	27	416.67
		24#	50	1.2	0.5	27	457.37
		35#	70	1.2	0.5	27	456.56
		36#	100	1.5	0.5	24	387.07
