KF300 servo-control series split-type intelligent filling system with high precision and low pulsation, driven by a servo motor. It consists of one controller and multiple (total 32) filling units. Units can be added or removed according to different requirements. Features a 4.3-inch true color touch-screen display.
Industry applications: Supports pharmaceutical machinery, filling equipment, pharmaceuticals, cosmetics, food, beverage dispensing, and oral liquid filling.
| Product Composition and Flow Rate Range |
| Model | Pump Head | Speed Range(rpm) | Tubing | Flow Rate(mL/min) |
| KF300 Plus | MiniPump | 0.1-300 | 1×1，2×1，2.5×1，3×1 13#，14#，16#，25# |
0.0024-190 |
| Filling Volume Reference(Media is water) |
| Drive | Pump Head | Tubing | mL/r | Filling Volume （mL） |
Filling Time （s） |
Accuracy （±%） |
Output （pcs/min） |
Motor Speed （rpm） |
| KF300 Plus | MiniPump | 13# | 0.027 | 0.06 | 0.8 | 3 | 33 | 166.67 |
| 13# | 0.027 | 0.1 | 1 | 2 | 30 | 222.22 | ||
| 13# | 0.027 | 0.2 | 2 | 0.8 | 20 | 222.22 | ||
| 14# | 0.114 | 0.8 | 1.5 | 0.8 | 24 | 280.70 | ||
| 14# | 0.114 | 1 | 2 | 0.5 | 20 | 263.16 | ||
| 19# | 0.248 | 2 | 2 | 0.5 | 20 | 241.94 | ||
| 16# | 0.377 | 3 | 2 | 0.5 | 20 | 238.73 |
